27'' Clinical Review Monitor for Modern Medical Workstations
Introducing the ME-2701, a 27” clinical review monitor thoughtfully crafted to revolutionise document scrutiny in clinics. Every meticulous detail is accentuated, enhancing patient record evaluations. Beyond its crisp display, the monitor champions safety with its IEC/EN 60601 certified power adaptor. Its sophisticated ergonomic design, combined with VESA mounting compatibility, promises versatility – from a traditional desk setup to the hustle and bustle of medical trolleys.

Crisp Image Quality
Tailored for medical precision, the ME-2701 features 2MP (1920 x 1080) resolution, offering unmatched clarity, facilitating accurate diagnostics and integration.

Safety First
Our monitor features an IEC/EN60601 certified power adaptor, ensuring safe, consistent operations.

Flexible Ergonomics
Whether it’s tilt, pivot, or swivel, find your perfect angle. Optimise efficiency and maintain comfort even during those extended reviews.

Versatile Mounting
Adaptability at its finest. With a 100 x 100mm VESA specification, mount the ME-2701 with ease, be it on dynamic medical trolleys or sleek wall setups.

Broad Connectivity
Integration has never been smoother. With HDMI and DisplayPort interfaces, ME-2701 caters to the diverse connectivity needs of modern medical systems.

Eye-Care Technology
Prioritising your well-being. Crafted for extended usage, our monitor minimises eye strain through its flicker-free performance and protective blue light filter.
Display
Display diagonal: 68.6 cm (27")
Display resolution: 1920 x 1080 pixels
HD type: Full HD
Native aspect ratio: 16:9
Display technology: LCD
Panel type: IPS
Display brightness (typical): 250 cd/m²
Response time: 5 ms
Feature: Anti-glare screen
Screen shape: Flat
Contrast ratio (dynamic): 20000000:1
Maximum refresh rate: 100 Hz
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Display number of colours: 16.7 million colours
Pixel pitch: 0.311 x 0.311 mm
Horizontal scan range: 30 - 112 kHz
Vertical scan range: 56 - 100 Hz
Display diagonal (metric): 68.6 cm
Performance
Feature: Flicker-free technology
Feature: Low Blue Light technology
Multimedia
Number of speakers: 2
RMS rated power: 4 W
Feature: Built-in speaker(s)
Design
Market positioning: Medical
Product colour: White
Feet colour: White
Ports & interfaces
Feature: HDMI
HDMI ports quantity: 1
HDMI version: 1.4
DisplayPorts quantity: 1
Feature: Headphone out
Headphone outputs: 1
Headphone connectivity: 3.5 mm
Ergonomics
Feature: VESA mounting
Panel mounting interface: 100 x 100 mm
Feature: Wall mountable
Feature: Cable lock slot
Cable lock slot type: Kensington
Feature: Height adjustment
Adjustable height (max): 12 cm
Feature: Pivot
Pivot angle: 0 - 90°
Feature: Swivelling
Swivel angle range: -45 - 45°
Feature: Tilt adjustment
Tilt angle range: -5 - 20°
Power
Energy efficiency class (SDR): E
Energy efficiency class (HDR): Not available
Energy consumption (SDR) per 1000 hours: 20 kWh
Energy consumption (HDR) per 1000 hours: 0 kWh
Power consumption (standby): 0.5 W
Power consumption (max): 20 W
Power consumption (off): 0.3 W
AC input voltage: 230 V
Power supply type: External
Energy efficiency scale: A to G
European Product Registry for Energy Labelling (EPREL) code: 1860358
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 10 - 85%
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Width (with stand): 612.2 mm
Depth (with stand): 190 mm
Height (with stand): 557 mm
Weight (with stand): 6.2 kg
Width (without stand): 612.2 mm
Depth (without stand): 46.7 mm
Height (without stand): 336.3 mm
Weight (without stand): 3.9 kg
Packaging data
Package width: 696 mm
Package depth: 188 mm
Package height: 437 mm
Package weight: 7.9 kg
Packaging content
Feature: Stand included
Cables included: AC, HDMI
Feature: Power adapter included
Feature: Quick start guide
Other features
Certification: CE, UKCA, LVD, WEEE, RoHS, REACH, EAC

AG Neovo ME-2701. Display diagonal: 68.6 cm (27"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LCD, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting, Height adjustment. Product colour: White
AG Neovo




MBR CODE - ME2710B1E0000
EAN - 4710739597653
